MC34151 High Speed Dual MOSFET Driver IC (DIP-8 Package)

Specification:-

• Power Supply Voltage: 20 V
• Logic Input: −0.3 to VCC V
• Gate Drive Output-Source Current: 1.5 A
• Maximum Power Dissipation = 50°C: 0.56 W
• Operating Junction Temperature: 150 °C
• Operating Ambient Temperature: 0 to +70 °C
• Storage Temperature Range: -65 to +150 °C
• Two Independent Channels with 1.5 A Totem Pole Output

CD4027 Dual JK Flip Flop IC (DIP-16 Package)

Specification:-

• Supply Voltage:  3V to +18V
• Noise margin (full package-temperature range) =
• 1 V at VDD = 5 V
• 2 V at VDD = 10 V
• 2.5 V at VDD = 15 V
• 5-V, 10-V, and 15-V parametric ratings
• Maximum input current of 1 µA at 18 V
• Temperature range; 100 nA at 18 V and 25°C

SG3524N Regulating pulse width modulator DIP 16 pins IC pack of 50pcs

Specification

1. Supply voltage range :  8V to 40V
2. Output voltage  :  5V
3. Output current  : 50 mA
4. Dual output
5. Topology  :  Boost, Buck, Fly-back, Forward, Push-Pull
6. Switching frequency :  722 kHz
7. Fall Time :  100 ns

7414 – Hex Schmitt Trigger SMD IC

Specification:-

• Mounting: SMD
• Supply Voltage: 7V
• Input voltage: 5.5V
• Temperature Range: -65°C to 150°C
• Operation From Very Slow Edges

MS51FB9AE 8-Bit Microcontroller IC 20-TSSOP Package Pack of 10

Specification:-

• Core Processor: 8051
• Core Size: 8-Bit
• Speed: 24MHz
• Voltage Supply: 2.4V ~ 5.5V
• Connectivity: I²C, SPI, UART/USART
• Operating Temperature: -40°C ~ 105°C
• Package/Case: 20-TSSOP

APR33A3 Voice Recorder & Playback IC

Specification:-

• Operating Voltage Range: 3V ~ 6.5V
• Standby Current: 1 µA
• VOUT Current: 185 mA
• Input Voltage: 0.6 V
• Operating Current (Idle): 20 mA
• Operating Current (Record): 35 mA
• Operating Current (Playback): 25 mA
• Powerful 16-Bits Digital Audio Processor

CD4511 BCD To 7 Segment Latch Decoder Driver IC (DIP-16 Package)

Specification:-

• Max. input current of 1 µA at 18 V
• 5-V, 10-V, and 15-V parametric ratings
• High-output-sourcing capability up to 25 mA
• 7-segment outputs blanked for BCD input codes > 1001

4056H 1A Standalone Linear Li-Ion Battery Charger IC 8-SOIC

Specification:-

• Package: SOIC8 (0.154", 3.90mm)
• Mounting Type: SMD/SMT
• Battery type : Li-Ion
• Supply voltage (input voltage) (min) : 4 V
• Supply voltage (input voltage) (max) : 8 V
• Output voltage (max) : 4.2
• Maximum output current (charge) (max) : 1 A
• Number of battery cells (Number of cells) : 1
• Operating temperature: -40 °C to 85 °C

74AC245PC Octal bidirectional transceiver with 3 state input and output DIP 20 pins IC pack of 50pcs

Specification

1. Octal bidirectional transceiver
2. Supply voltage : 2V to 6V
3. Power dissipation : 45pF
4. Input capacitance : 4.5pF
5. Leakage current : 3 µA

74HC138 3-to-8 line Decoder/Demultiplexer SMD IC

Specification:-

• Type: Quad
• Mounting: SMD
• Typical propagation delay: 20 ns
• Wide power supply range: 2V–6V
• Supply Voltage: − 0.5 to + 7.0V
• DC Input Voltage: − 1.5 to VCC + 1.5V
• DC Output Voltage: − 0.5 to VCC + 0.5V
• Low quiescent current: 80 µA

MCP3208 12-Bit 8-Channel A/D Converter (ADC) with SPI Interface IC DIP-16 Package

Specification:-

• Single supply operation: 2.7V – 5.5V
• 100ksps max. sampling rate at VDD = 5V
• 50ksps max. sampling rate at VDD = 2.7V
• Industrial temp range: -40°C to +85°C
• All Inputs and Outputs w.r.t. VSS: -0.6V to VDD +0.6V
• Storage Temperature: -65°C to +150°C
• Ambient temperature with power applied: -65°C to +125°C
• Soldering temperature of leads (10 seconds): +300°C
• ESD Protection On All Pins (HBM): ≥ 4 Kv

74LS00 Quad 2 Input NAND Gate IC DIP-14 Package

Specification:-

• Number of pins: 14
• Logic Function: NAND
• Product Type: Logic Gates
• Supply Voltage – Max: 5.25 V
• Supply Voltage – Min: 4.75 V
• Number of Gates: 4 Gate
• Number of Input Lines: 2 Input
