L6205 DMOS Dual Full Bridge Driver SMD IC

Specification:-

• Operating supply voltage from 8 to 52v
• 5.6a output peak current (2.8a dc)
• Rds(on) 0.3Ω typ. Value @ tj = 25 °c
• Operating frequency up to 100khz
• Non-dissipative overcurrent protection
• Paralleled operation

ADC0809 8-Bit A/D Converter with 8-Channel Multiplexer IC (DIP-28 Package)

Specification:-

• Number of input channels: 8
• Interface: Parallel
• Power consumption: 15 mW
• Input type: Single-Ended
• 8-Channel Multiplexer with Address Logic
• Operating temperature range: -40°C to 85°C

74HC151 8 – Input Multiplexer SMD IC

Specification:-

• Mounting: SMD
• Power Dissipation: 500 mW
• Supply Voltage: − 0.5 to + 7.0V
• DC Input Voltage: − 1.5 to VCC + 1.5V
• DC Output Voltage: − 0.5 to VCC + 0.5V
• DC Output Current, per pin: ± 25mA
• Operating Voltage Range: 2.0 to 6.0 V
• Low input current: 1 µA maximum
• Typical propagation delay: 26 ns

TD62783 8 Channel High-Voltage Source Driver SMD IC

Specification:-

• High output voltage: VCC: 50 V (min)
• Output current (single output): IOUT = −500 mA (min)
• Output clamp diodes
• Single supply voltage
• Input compatible with various types of logic

INA118 Low Power Instrumentation Op-Amplifier IC (DIP-8 Package)

Specification:-

• Packages: 8-Pin
• Supply Voltage: ±18 V
• Analog input voltage : ±40 V
• Wide supply range: ±1.35 to ±18 V
• Low quiescent current: 350 µA
• Low offset voltage: 50 µV, maximum
• Low drift: 0.5 µV/°C, maximum
• Low input bias current: 5 nA, maximum
• Storage temperature: -40°C to 125 °C

TO-92 78L06, 3-Terminal Positive Voltage Regulator IC pack of 5pcs

Specification

1. Output Current Up To 1.5 A
2. Input Voltage 5.76V To 6.24V
3. Thermal Overload Protection Short Circuit Protection
4. 2 % Output Voltage Tolerance
5. Output Transition SOA Protection

TDA7000 FM Radio Receiver IC

Specification:-

• Supply Voltage: 12V
• Frequency of 70 kHz
• Oscillator voltage: VP−0,5 to VP + 0,5 V
• Operating Temperature Range: 0°C to +60°C
• Storage temperature range: −55 to +150 °C

H8C1VB Encoder DIP 9 pins IC (Pack -10)

specification:

• Supply voltage:   2.4v& 12v
• Material:    plastic package with metal pins.
• chip of a semiconductor
• High quality product
• Bettar work with HT12D Dicoder

74LS47 BCD to 7-Segment Decoder/Driver IC DIP-16 Package

Specification:-

• Number of pins: 16
• Supply Voltage (VCC): 7 V
• Input Voltage (VI): 7 V
• Operating free-air temperature range: 0°C to +70°C
• Storage temperature range: –65°C to +150°C

74LS90 Decade Counter SMD IC

Specification:-

• Supply Voltage: 4.5 to 5.5V
• Output Current: -0.4 to 8mA
• Low Power Consumption : Typically 45 mW
• High Count Rates : Typically 42 MHz
• Temperature Range: -55°C to 125°C

CD4067 16-Channel Analog Multiplexer/Demultiplexer IC (DIP-24 Package)

Specification:-

• Supply current: 0.04 uA
• 5-V, 10-V, and 15-V parametric ratings
• 100% tested for quiescent current at 20 V
• Maximum input current of 1 µA at 18 V
• Temperature range; 100nA at 18 V and 25°C
• Low ON resistance: 125  (typ.) over 15 Vp-p signal-input range for VDD – VSS = 15 V
• High OFF resistance: channel leakage of ±10 pA (typ.) @ VDD – VSS = 10 V
• Matched switch characteristics: RON = 5 (typ.) for VDD – VSS = 15 V

CD4053 Triple 2-channel Multiplexer/Demultiplexer SMD IC

Specification:-

• DC Supply Voltage: -0.5V to +18V
• Input Voltage: -0.5V to VDD +0.5V
• Storage Temperature: -65°C to +150°C
• Power Dissipation: 700 mW
• Lead Temperature: 265°C
