74HC374 3-State Output Octal D-Type Flip-Flop IC DIP-20 Package
Specification:-
- Number of pins: 20
- Frequency: 70MHz
- Current Rating: 7.8mA
- Propagation Delay: 20ns
- Wide operating voltage range: 2 to 6V
- Operating Temperature (°C): − 40°C to + 85°C
SKU: UB2605A
74HC374 3-State Output Octal D-Type Flip-Flop IC DIP-20 Package
The 74HC374 is an octal D-type flip-flop IC with 3-state outputs, available in a DIP-20 package. This IC is primarily used for data storage, data transfer, and buffering in digital circuits. It contains eight D-type flip-flops, each with its own 3-state output, allowing it to store and transfer data for up to eight individual bits simultaneously. When the enable pin is activated, data is latched from the D inputs to the Q outputs on the rising edge of the clock pulse, providing synchronous operation. The 74HC374 operates over a supply voltage range of 2V to 6V, making it compatible with both TTL and CMOS logic levels. Each output can be set to high, low, or high-impedance (tri-state) mode, which is ideal for bus-oriented systems. In tri-state mode, the outputs are effectively disconnected, allowing multiple ICs to share the same data lines without interference. This feature is useful in situations requiring multiple data sources, like memory address buses and I/O interfaces in microcontroller systems.
Features:-
- DIP-20 Package
- Low Power Consumption
- High-Speed Performance
- Wide Operating Voltage Range
- Octal D-Type Flip-Flop
- Edge-Triggered Latching
