MAX488 RS-485/RS-422 Line Driver/Receiver IC (DIP-8 Package)

MAX488 RS-485/RS-422 Line Driver/Receiver IC (DIP-8 Package)

The MAX488 is an RS-485/RS-422 Line Driver/Receiver IC packaged in a DIP-8 form factor, designed to facilitate high-speed, long-distance data transmission over differential communication lines. This IC supports RS-485 and RS-422 standards, making it suitable for various industrial, automation, and communication applications. The MAX488 provides a reliable solution for transmitting data over twisted-pair cables in environments requiring robust signal integrity and noise resistance. Operating at data rates up to 2.5 Mbps, the MAX488 is capable of handling fast communication in systems where low power consumption is essential. It features differential signaling, which provides superior noise immunity, making it ideal for environments with electrical interference. The IC supports a wide voltage range of 4.5V to 5.5V, ensuring compatibility with various system voltages. Additionally, it integrates both the line driver and line receiver functions, simplifying circuit design by reducing the number of required components. The MAX488 can drive up to 32 transceivers on a bus, supporting multipoint communication, and includes fail-safe protection against bus contention and short circuits. This versatility makes the MAX488 suitable for applications like industrial networks, sensor data acquisition systems, and industrial control systems, where reliable and efficient communication over long distances is essential.

Features:-

• Low power consumption
• Compact and Easy Integration
• High-Speed Operation
• Dual Functionality
• Multipoint Capability
