TIP31C NPN Transistors 100V (TO-220 Package) Pack of 5
- Transistor Polarity - NPN
- Collector-Emitter Voltage (VCEO) - 100V
- Continuous Base Current (IB) - 1A
- Continuous Collector Current (IC) - 3A
- Emitter cut-off current (IC) - 500mA
- Operating Temperature Range - (-65 - 150°C)
- Transition Frequency (fT) - 3MHz
SKU: VG8541E
TIP31C NPN Transistors 100V (TO-220 Package) Pack of 5
TIP31C is a power transistor of the NPN type. It has a gain value of 50 and a 3A collector current. TIP31C is a three-layer NPN device that operates within its operational range; given a specific collector-emitter voltage, a change in the base current causes a change in the collector current, which is amplified in proportion to the change in the base current. A base island technology NPN power transistor in a TO-220 plastic packaging is called the TIP31C. It performs better than the TIP31C used by the industry as a whole, making it appropriate for use in switching, power linear, and audio applications. TIP31C is a three-layer NPN device that operates within its operating range; a change in the base current results in a change in the collector current that is amplified in proportion to the change in the base current for a certain collector-emitter voltage base island technology NPN power transistor in a TO-220 plastic packaging is called the TIP31C. Because of its improved performance above the industry norm TIP31C, it can be used in switching, audio, and power linear applications.
Features:-
- Low saturation voltage
- Simple drive requirements
- High safe operating area
- For low distortion complementary designs
- Easy to carry and handle
- High switching speed
