IC

AD736 True RMS to DC Converter SMD IC

Specification:-

• Mounting: SMD
• Number of: 8 Pins
• High input impedance: 1012 Ω
• Low input bias current: 25 pA maximum
• High accuracy: ±0.3 mV ± 0.3% of reading
• RMS conversion with signal crest factors up to 5
• Wide power supply range: +2.8 V, −3.2 V to ±16.5 V
• Low power: 200 µA maximum supply current

AT24C01A-10PC EEPROM Memory IC 8-PDIP

Specification:-

• Package: PDIP-8 (0.300", 7.62mm)
• No. of Pins: 8-Pins
• Mounting Type: Through Hole
• Memory Size: 1 Kbit
• Access Time: 900 ns
• Maximum Clock Frequency: 0.4 MHz
• Supply Voltage Min: 4.5 V
• Supply Voltage Max: 5.5 V
• Operating Temperature: 0°C to 70°C

ADM691AR Supervisor SMD IC 1-Channel 16-SOIC

Specification:-

• Package: SOIC-16 (0.295", 7.50mm)
• No. of Pins: 16
• Mounting Style: SMD/SMT
• Supply Voltage-Max (Vsup): 5.5 V
• Supply Voltage-Min (Vsup): 4.75 V
• Supply Voltage-Nom (Vsup): 5 V
• Operating Temperature: -40°C to 85°C

CD40175 Quad D-Type FlipFlop IC (DIP-16 Package)

Specification:-

• DC Supply Voltage Range, (VDD): -0.5V to +20V
• Input Voltage Range, All Inputs: -0.5V to VDD +0.5V
• Operating Temperature Range: -55°C to +125°C
• DC Input Current, Any One Input: ±10mA
• Storage Temperature Range (TSTG): -65°C to +150°C
• Lead Temperature (During Soldering): +265°C

AT24C128N-10SI-1.8 EEPROM Memory IC 8-SOIC

Specification:-

• Package: SOIC8 (0.154", 3.90mm)
• No. of Pins: 8Pins
• IC Mounting: Surface Mount
• Supply Voltage Min: 1.8V
• Supply Voltage Max: 2.5V
• Clock Frequency: 400 kHz
• Access Time: 900ns
• Program Memory Size: 128Kb (16K x 8)
• Operating Temperature: -40°C to 85°C

HI7190IP 24-Bit High Precision Sigma-Delta A/D Converter IC (DIP-20 Package)

Specification:-

• 22-Bit Resolution with No Missing Code
• 0.0007% Integral Non-Linearity (Typ)
• 20mV to ±2.5V Full Scale Input Ranges
• Internal PGIA with Gains of 1 to 128
• Temperature Range -40°C to 85°C
• Serial Data I/O Interface, SPI Compatible

74LS73 Dual JK Flip-Flop with Clear IC DIP-14 Package

Specification:-

• Number of pins: 14
• Supply Voltage (VCC): 7 V
• Input Voltage (VI): 7 V
• Operating free-air temperature range: 0°C to +70°C
• Storage temperature range: –65°C to +150°C

TP223-BA6 IC (SOT23-Package) Pack of 2

Specification:-

• Operating voltage 2.0V~5.5V
• Operating current: 3V
• Startup Calibration Delay: 0.5 Sec
• Capacitance: 0~50pF
• Number of pin: 6
• Simple to Use

CA3161 IC + CA3162 IC Pair A/D Converter for 3 Digit Display DIP-16 Package

Specification:-

CA3161 IC

• DC V SUPPLY: +7.0 V
• Input Voltage: +5.5 V
• Output Voltage: +7 V
• Power Dissipation: 18mW (Typ)

CA3162 IC

• DC V SUPPLY: +7.0 V
• Input Voltage: +15 V
• Temperature Range: 0°C to 75°C
• Low Speed (4Hz) or High Speed (96Hz) Conversion Rate

CD4538 Dual Precision Monostable Multivibrator SMD IC

Specification:-

• Wide supply voltage range: 3.0V to 15V
• High noise immunity: 0.45 VCC (typ.)
• DC Supply Voltage: -0.5 to +18 VDC
• Input Voltage: -0.5V to VDD + 0.5 VDC
• Storage Temperature: -65°C to +150°C
• Low standby current: 5 nA (typ.) @ 5 VDC
• Power Dissipation: 700 mW
• Lead Temperature: 260°C

AM26LV32 Low-Voltage High-Speed Quadruple Differential Line Receiver SMD IC

Specification:-

• Mounting: SMD
• Number of: 16 Pins
• Input Hysteresis: 50 mV Typical
• Operates From Single 3.3-V Supply
• Ultra-Low Power Dissipation: 27 mW Typical
• Switching Rates Up to 32 MHz
• 235 mW With Four Receivers at 32 MHz

ADM1024ARU PC PDA's Interface SMD IC 24-TSSOP

Specification:-

• Package: TSSOP24 (0.173", 4.40mm)
• No. of Pins: 24 Pins
• Mounting Type: Surface Mount
• Supply Voltage-Max (Vsup): 5.5 V
• Supply Voltage-Min (Vsup): 2.8 V
• Supply Voltage-Nom (Vsup): 3.3 V
• Applications: PC's, PDA's
