IC

CA3161 IC + CA3162 IC Pair A/D Converter for 3 Digit Display DIP-16 Package

Specification:-

CA3161 IC

• DC V SUPPLY: +7.0 V
• Input Voltage: +5.5 V
• Output Voltage: +7 V
• Power Dissipation: 18mW (Typ)

CA3162 IC

• DC V SUPPLY: +7.0 V
• Input Voltage: +15 V
• Temperature Range: 0°C to 75°C
• Low Speed (4Hz) or High Speed (96Hz) Conversion Rate

74HC574 Tri State Octal D Type Flip-Flop SMD IC

Specification:-

• Mounting: SMD
• Operating Voltage Range: 2 V – 6 V
• Supply Voltage: − 0.5 to + 7.0V
• DC Input Diode Current: ±20 mA
• DC Output Diode Current: ±20 mA
• Operating Temperature: 65°C to 150°C

TP223-BA6 IC (SOT23-Package) Pack of 2

Specification:-

• Operating voltage 2.0V~5.5V
• Operating current: 3V
• Startup Calibration Delay: 0.5 Sec
• Capacitance: 0~50pF
• Number of pin: 6
• Simple to Use

AT89C4051-24SU 89C-Microcontroller IC 8-Bit 24MHz 4KB (20-SOIC)

Specification:-

• Package: SOIC-20 (0.295", 7.50mm)
• No. of Pins: 20
• Speed: 24MHz
• Core Processor: 8051
• Data RAM Size: 128 B
• Program Memory Type: FLASH
• Program Memory Size: 4KB (4K x 8)
• Operating Supply Voltage: 2.7 V to 6 V
• Mounting Type: Surface Mount

L272 Dual Power Operational Amplifiers SMD IC

Specification:-

• IC Name: L272
• Output current to 1 a
• Operates at low voltages
• Single or split supply
• Ground compatible inputs
• Low saturation voltage
• Thermal shutdown

CD4011 Quad 2-Input NAND Gate IC (DIP-14 Package)

Specification:-

• Voltage: 3V to 18V
• Input type: Standard CMOS
• Output type: Push-Pull
• Data rate (Max): 8 (Mbps)
• Noise margin (over full package temperature range:
• 1 V at VDD = 5 V
• 2 V at VDD = 10 V
• 2.5 at VDD = 15 V
• 5-V, 10-V, and 15-V parametric ratings
• Operating Temperature Range: -55°C to + 125°C

MCP4921 12-Bit Digital to Analog Converter (DAC) with SPI Interface IC (DIP-8 Package)

Specification:-

• Supply Voltage: 2.7V to 5.5V
• Current at Input Pins: ±2 m A
• Current at Supply Pins: ±50 m A
• Current at Output Pins: ±25 m A
• All Inputs and Outputs w.r.t. VSS: VSS –0.3V to VDD+0.3V
• Storage Temperature: -65°C to +150°C
• Ambient temperature with power applied: –55°C to +125°C
• Soldering temperature of leads (10 seconds): +300°C

DW06D/S 2-in-1 Lithium Battery Protection IC SOT-23-6

Specification:-

• Package: SOT-23-6
• High-precision voltage detection
• Voltage Thresholds: Overcharge at 4.25V ± 0.05V, over-discharge at 2.50V ± 0.10V.
• Low quiescent current consumption: normal operating current 3.8uA
• Low Power Consumption

CD4516 Binary Up Down Counter DIP IC

Specification:-

• Medium-speed operation – fCL = 8 NHz typ. at 10 V.
• 5-V, 10-V, and 15-V parametric ratings
• 100% tested for quiescent current at 20 V
• Maximum input current of 1 µA at 18 V
• Temperature Range; 100nA at 18V and +25°C

74LS95 4-bit Parallel-Access Shift Register IC DIP-14 Package

Specification:-

• Number of pins: 14
• ISupply Voltage: 4.5 to 5.5V
• Output Current: -0.4 to 8m A
• 4-Bit Storage
• Temperature Range: -55°C to + 125°C

ADM1024ARU PC PDA's Interface SMD IC 24-TSSOP

Specification:-

• Package: TSSOP24 (0.173", 4.40mm)
• No. of Pins: 24 Pins
• Mounting Type: Surface Mount
• Supply Voltage-Max (Vsup): 5.5 V
• Supply Voltage-Min (Vsup): 2.8 V
• Supply Voltage-Nom (Vsup): 3.3 V
• Applications: PC's, PDA's

LF356 JFET Input Op-Amplifier IC (DIP-8 Package)

Specification:-

• Supply Voltage: ±18 V
• Input voltage: ±16 V
• Differential input voltage: ±30 V
• Low Input Bias Current: 30 pA
• Low Input Offset Current: 3 pA
•  High Input Impedance: 1012 Ω
• Operating temperature: -40 °C to 125 °C
• Storage temperature: -65 °C to 150 °C
