IC

MCP3202 12-Bit Dual Channel A/D Converter (ADC) with SPI Interface IC (DIP-8 Package)

Specification:-

• Single supply operation: 2.7V – 5.5V
• 100ksps max. sampling rate at VDD = 5V
• 50ksps max. sampling rate at VDD = 2.7V
• All Inputs and Outputs w.r.t. VSS: -0.6V to VDD +0.6V
• Storage Temperature: -65°C to +150°C
• Ambient temperature with power applied: -65°C to +125°C
• Soldering temperature of leads (10 seconds): +300°C
• ESD Protection On All Pins (HBM): ≥ 4 Kv

DS3695 Multipoint RS485/RS422 Transceivers SMD IC

Specification:-

• Mounting: SMD
• Number of: 8 Pins
• Supply voltage range: 4.75V to 5.25V
• 70 mV typical receiver hysteresis
• Temperature Range: 0°C to + 70°C

CA3161 IC + CA3162 IC Pair A/D Converter for 3 Digit Display DIP-16 Package

Specification:-

CA3161 IC

• DC V SUPPLY: +7.0 V
• Input Voltage: +5.5 V
• Output Voltage: +7 V
• Power Dissipation: 18mW (Typ)

CA3162 IC

• DC V SUPPLY: +7.0 V
• Input Voltage: +15 V
• Temperature Range: 0°C to 75°C
• Low Speed (4Hz) or High Speed (96Hz) Conversion Rate

74HC86 Quad 2-Input EXOR Gate IC DIP-14 Package

Specification:-

• Number of pins: 14
• Gate IC Type: XOR
• Mounting: Through Hole
• Operating Voltage (V): 2 to 6
• Low Noise: VOLP = 0.8 V (Max)
• Input Clamping Current: ± 20 mA
• Operating Temperature (°C): -55°C ~ +125°C

74HC540 Octal 3-state Inverting Buffer IC SMD IC

Specification:-

• Mounting: SMD
• Power Dissipation: 500 mW
• Operating Voltage Range: 2 V – 6 V
• Supply Voltage: − 0.5 to + 7.0V
• DC Input Voltage: –0.5 to VCC + 0.5
• DC Output Voltage: −0.5 ≤ VO ≤ VCC + 0.5
• Operating Temperature: 65°C to 150°C

ADM708TAR-TR Supervisor SMD IC 1-Channel 8-Pin SOIC

Specification:-

• Package: SOIC-8 (0.154", 3.90mm)
• No. of Pins: 8
• Supply Current (Typ): 250 uA
• Output: Push-Pull, Push-Pull
• Supply Voltage-Max (Vsup): 5.5 V
• Supply Voltage-Min (Vsup): 3.15 V
• Supply Voltage-Nom (Vsup): 5 V
• Operating Temperature: -40°C to 85°C

IR2104 Half Bridge Driver IC (DIP-8 Package)

Specification:-

• High side floating supply voltage: -0.3 to 625 V
• High side floating supply offset voltage: VB -25 to VB +0.3 V
• High side floating output voltage: -0.3 to VB +0.3 V
• Low side and logic fixed supply voltage: -0.3 to 25V
• Low side output voltage: -0.3 to VCC+0.3 V
• Logic supply Voltage: -0.3 to VSS+0.3 V

AD8044AR-14 Amplifier 4-Channel SMD IC Rail-to-Rail 14-SOIC

Specification:-

• Package: SOIC-14 (0.154", 3.90mm)
• No. of Pins: 14
• Number of Circuits: 4
• Output Type: Rail-to-Rail
• Voltage - Input Offset: 1.4 mV
• Operating Supply Voltage: 3 V to 12 V
• Operating Temperature: -40°C to 85°C
• Mounting Style: SMD/SMT

L272 Dual Power Operational Amplifiers SMD IC

Specification:-

• IC Name: L272
• Output current to 1 a
• Operates at low voltages
• Single or split supply
• Ground compatible inputs
• Low saturation voltage
• Thermal shutdown

24LC256 256K bit Serial I2C Bus EEPROM IC (DIP-8 Package)

Specification:-

• Single Supply with Operation Down to 2.5V
• All inputs and outputs w.r.t. VSS: -0.6V to VCC +1.0V
• Storage temperature: -65°C to +150°C
• Ambient temperature with power applied: -40°C to +125°C
• ESD protection on all pins: ≥ 4 kV°C
• 100 kHz, 400 kHz and 1 MHz Compatibility

AS7C256A-15JC SRAM - Asynchronous Memory IC 256Kbit Parallel 15ns 28-SOJ

Specification:-

• Memory Size: 256Kbit (32K x 8-bit)
• Access Time: 15ns
• Technology: CMOS
• Package: 28-pin SOJ
• Supply Current-Max 0.065 mA
• Supply Voltage-Max (Vsup): 5.5 V
• Supply Voltage-Min (Vsup): 4.5 V
• Supply Voltage-Nom (Vsup): 5 V

74LS06 Hex Inverter Buffer IC DIP-14 Package

Specification:-

• Number of pins: 14
• Supply Voltage (VCC): 7 V
• Input Voltage (VI): 5.5 V
• Output Voltage (VO): 30 V
• Operating free-air temperature range: 0°C to 70°C
• Storage temperature range: -65°C to 150°C
