SENSOR MODULES

GP2Y1010AU0F Dust and smoke particle detection sensor module

Specifications:-

1. Sensitivity : 0.5V/(100μg/m3)
2. Measurement range : 500μg/m3
3. Power : 2.5V to 5.5V
4. Operating current : 20mA(max)
5. Operating temperature : -10℃ to 65℃

100-265 AC 200W/1200W Infrared Motion Sensor Switch

Specification:-

• Power source: 100-265V AC
• Power consumption: 0.5W (static 0.1W)
• Detection speed: 0.6 ~1.5m/s
• Time setting: Min: 10±2sec
• Max: 7±2min(adjustable)
• Light-control: <10~2000LUX(adjustable)
• Detection range: 6m Max (24°C)
• Detection angle: 120°(side view)360°(top view)
• Installation height: 2.5m~3.5m;
• Working temperature: -10°C~+40°C
• Working humidity: <93%RH

MQ-9 Carbon monoxide, Methane and LPG gas detection sensor module

Specifications:-

1. Operating voltage : 5V
2. Heat consumption : 340mW
3. Heat resistance : 33Ω±5%
4. Sensing resistance : 2 - 20000Ω
5. Detecting concentration : 10000ppm

MQ-4 Methane and smoke gas detector sensor module

Specifications:-

1. Operating voltage : 3V to 5V
2. Wide detecting scope
3. Fast response and High sensitivity
4. Stable and long life
5. Detect/Measure : Methane, Natural gases, etc.

MQ-6 Butane, LPG and smoke detection sensor module

Specifications:-

1. Operating Voltage: +5V
2. Can be used to detect LPG or Butane gas
3. Analog output voltage: 0V to 5V
4. Digital Output Voltage : 0V or 5V (TTL Logic)
5. Preheat duration 20 seconds
6. Can be used as a Digital or analog sensor

BFD-1000 5 channel line follower sensor module

Specifications:-

1. Detecting distance: 0-4cm (black line sensor) 0-5cm (adjustable distance detection)
2. Input voltage: 3.0-5.5V
3. Output Type: Digital output (high and low)

PH 3 in 1 Soil Moisture Sensor Meter

Specification:-

• Measurement Functions: Soil moisture, soil pH, light intensity
• Display Type: Analog dial
• Power Source: No batteries required
• Material: Durable plastic housing with metal probes
• Dimensions: Compact and lightweight for portability

110-240 AC 300W/1200W Automatic Infrared Motion Sensor Switch

Specification:-

• Power source: 110-240V AC
• Power consumption: 0.45W (static 0.1W)
• Time delay: Min: 8s±3sec
• Light-control: <3LUX(adjustable)
• Detection range: 12m Max (24°C)
• Detection angle: 180°
• Installation height: 1.8m~2.5m
• Working temperature: -10°C~+40°C
• Working humidity: <93%RH

Tilt Ball Vibration Sensor Switch

Specification

• Switch type: Tilt
• Voltage: 6V
• Current: 0.1mA-5Ma
• Temperature range: 25 to 85C
• Operating lifespan: above 30,000 hours

MQ-7 Carbon monoxide gas detection sensor module

Specifications:-

1. Sensor type: semiconductor
2. Target gas: carbon monoxide
3. Detection range: 10～500ppm CO
4. Working voltage: 5V
5. Heat resistance: normal room temperature

TCRT5000 Dual Channel Line Tracking sensor module

Specifications:-

1. Module model : TCRT5000
2. Working voltage : DC 3.5V to 5V
3. Output channel : 0/1
4. Detect distance : 1-25mm
5. Focal distance : 2.5mm
6. IC name : LM393
7. Inbuilt indicator light
8. Also, built in potentiometer for sensitivity

5V-15V DC NE555 Pulse Frequency Duty Cycle Adjustable Module Square Wave Signal Generator

Specification:-

• Main chip: NE555
• Input Voltage: 5V-15V DC
• Maximum output current: 15MA
• Generate an adjustable pulse for MCU
• Generate an adjustable pulse, to control circuitry associated
