IC

74HC540 Octal 3-state Inverting Buffer IC SMD IC

Specification:-

• Mounting: SMD
• Power Dissipation: 500 mW
• Operating Voltage Range: 2 V – 6 V
• Supply Voltage: − 0.5 to + 7.0V
• DC Input Voltage: –0.5 to VCC + 0.5
• DC Output Voltage: −0.5 ≤ VO ≤ VCC + 0.5
• Operating Temperature: 65°C to 150°C

CA3161 IC + CA3162 IC Pair A/D Converter for 3 Digit Display DIP-16 Package

Specification:-

CA3161 IC

• DC V SUPPLY: +7.0 V
• Input Voltage: +5.5 V
• Output Voltage: +7 V
• Power Dissipation: 18mW (Typ)

CA3162 IC

• DC V SUPPLY: +7.0 V
• Input Voltage: +15 V
• Temperature Range: 0°C to 75°C
• Low Speed (4Hz) or High Speed (96Hz) Conversion Rate

74HC00 Quad 2-Input NAND Gate IC DIP-14 Package

Specification:-

• Number of pins: 14
• Mounting: Through Hole
• Voltage Rating: 2 to 6V
• Operating Temperature:  -40°C to + 125°C
• Four Independent NAND Gates

MC33151 High Speed Dual MOSFET Driver IC (DIP-8 Package)

Specification:-

• Power Supply Voltage: 20 V
• Logic Input: VEE −0.3 to VCC V
• Totem Pole Sink or Source Current: 1.5 A
• Maximum Power Dissipation  = 50°C: 0.56 W
• Maximum Power Dissipation = 50°C: 1W
• Operating Junction Temperature: 150 °C
• Operating Ambient Temperature: 0 to 70 °C
• Storage Temperature Range: -65 to +150 °C

AD8044AR-14 Amplifier 4-Channel SMD IC Rail-to-Rail 14-SOIC

Specification:-

• Package: SOIC-14 (0.154", 3.90mm)
• No. of Pins: 14
• Number of Circuits: 4
• Output Type: Rail-to-Rail
• Voltage - Input Offset: 1.4 mV
• Operating Supply Voltage: 3 V to 12 V
• Operating Temperature: -40°C to 85°C
• Mounting Style: SMD/SMT

AS7C256A-15JC SRAM - Asynchronous Memory IC 256Kbit Parallel 15ns 28-SOJ

Specification:-

• Memory Size: 256Kbit (32K x 8-bit)
• Access Time: 15ns
• Technology: CMOS
• Package: 28-pin SOJ
• Supply Current-Max 0.065 mA
• Supply Voltage-Max (Vsup): 5.5 V
• Supply Voltage-Min (Vsup): 4.5 V
• Supply Voltage-Nom (Vsup): 5 V

ULN2804APG High Voltage Darlington Transistor Arrays IC (DIP-18 Package)

Specification:-

• Mounting Type: Through Hole
• Number of Channels: 8
• Output Current: 500 mA
• Output Voltage: 50 V
• CE Breakdown Voltage: 50 V
• CE Voltage (VCEO): 50 V
• Max Power Dissipation: 76 mW
• Operating Temperature: -40°C ~ 80°C

AT89C4051-24SU 89C-Microcontroller IC 8-Bit 24MHz 4KB (20-SOIC)

Specification:-

• Package: SOIC-20 (0.295", 7.50mm)
• No. of Pins: 20
• Speed: 24MHz
• Core Processor: 8051
• Data RAM Size: 128 B
• Program Memory Type: FLASH
• Program Memory Size: 4KB (4K x 8)
• Operating Supply Voltage: 2.7 V to 6 V
• Mounting Type: Surface Mount

74HC85 4-bit Magnitude Comparator IC DIP-16 Package

Specification:-

• Number of pins: 16
• ICC category: MSI
• Mounting: Through Hole
• Powering Current: 160 uA
• Operating Voltage (V): 2 to 6
• Output Current at VCC: 4 mA
• Operating Temperature (°C): -65°C ~ +125°C

ADM708TAR-TR Supervisor SMD IC 1-Channel 8-Pin SOIC

Specification:-

• Package: SOIC-8 (0.154", 3.90mm)
• No. of Pins: 8
• Supply Current (Typ): 250 uA
• Output: Push-Pull, Push-Pull
• Supply Voltage-Max (Vsup): 5.5 V
• Supply Voltage-Min (Vsup): 3.15 V
• Supply Voltage-Nom (Vsup): 5 V
• Operating Temperature: -40°C to 85°C

74LS05 Hex Inverters with Open-Collector SMD IC

Specification:-

• Mounting: SMD
• Supply Voltage: 4.75 to + 5.25V
• Output Current: 8mA
• Operating Temperature: 0°C to 70°C
• Six Independent INVERT Gates
• Standard TTL Switching Voltages

ADM691AR Supervisor SMD IC 1-Channel 16-SOIC

Specification:-

• Package: SOIC-16 (0.295", 7.50mm)
• No. of Pins: 16
• Mounting Style: SMD/SMT
• Supply Voltage-Max (Vsup): 5.5 V
• Supply Voltage-Min (Vsup): 4.75 V
• Supply Voltage-Nom (Vsup): 5 V
• Operating Temperature: -40°C to 85°C
